Overview
Type:
Shot Blast Cleaning (Peening / Airless)
Manufacturer:
OCEAN MACHINERY
Model:
BLASTER
Status:
For Sale
Description

Ocean and its manufacturing partner Agtos, have produced a completely unique shot blast machine for cleaning structural steel sections. The new ultra-compact, fully integrated, exceptionally efficient shot blast machine will fit any steel fabricators space and budget requirements. The entire Ocean Blaster, including dust extraction unit, requires only 13ft x 23ft of floor space and only 14ft of headroom (4m x 7m x 4m), making it ideal for even the smallest fabricating shops. Despite its compact size the Blaster will handle all profiles up to 40" tall and 20" wide (1m x 500mm). The exceptionally efficient turbine design allows fabricators to clean steel with the lowest power consumption, reducing costs even further. And pre-blasting steel reduces grinding and cleaning, reduces rework, and creates a clean work environment improving morale and safety.

Specifications

Maximum Profile Height 40″ (1000mm) Maximum Profile Width 20″ (500mm) Minimum Work Piece Height 0.5″ (10mm) Minimum Work Piece Length 80″ (2000mm) Maximum Weight of Work Piece 500 lbs/ft (750kg/m) Number of Wheels 4 Diameter 15″ (380mm) at 50Hz, 13″ (330mm) at 60Hz Number of Blades 6 Blade Width 2.16″ (55mm) Turbine Drive 10hp (7.5kW) Abrasive Flow Per Turbine 300 lbs/min (135kg/min) Abrasive Throwing Speed approx. 290 ft/sec (88m/sec)
