INSPECVISION - PLANAR VISION INSPECTION SYSTEM

Description

Planar vision inspection system explicitly designed for speed, accuracy, and ease of use. The 2D process can measure every feature completely. Planar can produce multiple report types automatically with minimal input from the operator. To inspect the operator places the part on the measurement surface and with a single click or scan of a barcode.

- Extract the relevant profile data.
- Extract all dimensions and tolerance data from the layers.
- Use this information to generate reports automatically.
- Measure the part.
- Fill in reports with measured data, nominal data, tolerance information and will indicate all PASS/FAIL items.
