The 1000-series of machines are built in a heavy duty construction with a smaller footprint designed to accommodate a job shop with various applications such as deburring, dross removal, calibrating/dimensioning, edge radiusing or finishing. This series of machine can be built in both top and bottom configurations.
Machines built in widths from 13″ to 43″ and multiple head frames
Dual infeed and outfeed pinch rolls to ensure parts feed through machine properly
One- to three-head configurations with drum, brush, disc or combination drum/brush/disc heads
Machines built in both top and bottom configurations
Individual cam adjustment down to .001″ per head for accurate finishing
Air-loaded cylinder for automated belt tensioning
Automatic abrasive belt tracking to ensure proper belt alignment during operation
Belt Width: 13" to 43"
Motor Size: 5 HP to 30 HP
Number of Heads: 1 to 3
Types of Heads
Available: Drum, Scotch-Brite, Brush and Disc
Drum Size: 100 mm to 200 mm
Configuration: Top-Only, Bottom-Only, or Top/Bottom Configuration
Feed Motor: 1 HP to 3 HP
