Manual double self-centering vise assures burr-free cuts
Operator controlled trigger switch
Miter locking device stops: 45 degree left, 90 degree and 45 degree right
Capable of slotting
Double reduction, hardened and ground worm and wheel gear box
Chip drawer
7 Gallon flood coolant tank with pump
One 250 mm diameter HSS blade
One blade wrench
One gallon coolant
Complies with ANSI B11.10 safety standards
Warranty: Three years on parts
Made in USA
Cutting Speeds
(specify when ordering)
LT(Low Turn) - designed for solid mild steel, solid stainless steel & thick wall pipe LT
30 / 60 rpm Motor rate: 2 hp
HT(High Turn) - designed for thin wall tube 0.060 wall thickness or thinner and non-ferrous material HT
60 / 120 rpm Motor rate:
1.5 hp
SS(Single Speed) - designed for 220v 1ph applications SS
60 rpm Motor rate:
2 hp
Maximum Cutting Capacities
(with 275 mm blade)
TUBING
Round
Square
Rectangle
90 Degree:
3-3/8"
3" x 3"
3" x 2-3/8"
45 Degree:
2"
2" x 2"
2" x 2"
SOLID
Round
Square
90 Degree:
1-1/2"
1-1/2" x 1-1/2"
45 Degree:
1"
1" x 1"
Motor Options:
(Factory Wired)
Specify:
LT & HT: 208/230/460/575v, 3 ph
SS: 220v, 1 ph
Maximum Diameter Blade: 275 mm
Arbor Bore 32 mm
Pin Spacing 2/8/45
Width 21-7/8" 55.5 cm
Depth 43-1/2" 110.5 cm
Height (not incl feed handle) 53-1/4" 135 cm
Height (floor to vise) 36-1/8" 92 cm
Shipping Weight
(may vary) 550 lbs. 279 kg
